Online Water Analyzer

Online Water Analyzer Specification

Measurement Range
0 to 14 pH

Dimension (L*W*H)
225mm x 175mm x 85mm

Mounting
Panel/Wall mounted

Application Media
Water, Industrial Effluent, Wastewater

Resolution
0.01 pH

Frequency
50 Hz

Measuring Units
pH

Process Connection
Threaded

Sensor Type
Glass Electrode

Protection
IP65

Flow Rate
0.2 - 1.0 L/min (sampling)

Diameter
Sensor probe: 12 mm

Language
English

Storage Temperature
-10C to 70C

Current Range
4-20 mA

Output
4-20 mA

Pressure Range
0-6 Bar

Temperature Range
0 - 60C

Connecting Type
Screw Terminal

Stability
0.1 pH

Response Time
30 Sec

Operating Temperature
0C to 60C

Color
Grey/Black

Signal Type
Analog

Humidity %
90% RH (non-condensing)

Equipment Type
Online Water Analyzer

Connectivity Type
Wired

Length
Cable: 5M Standard

Material
Stainless Steel & ABS

Power Supply
220V AC, 50Hz

Power Consumption
10W

Accuracy
2% FS

Display Type
Digital LCD

Range
0-14 pH

Electrode Life
12-18 Months (Typical)

Data Output Interface
RS485 MODBUS (Optional)

Compliance
CE Certified

Data Logging
Optional

Installation Accessories
Mounting Bracket, Cable Gland Included

Calibration
2 or 3 Point Automatic Calibration

Alarm Function
High/Low pH Adjustable

Online Water Analyzer Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About Online Water Analyzer

Experience stellar performance with our Elite Online Water Analyzer, designed for outstanding pH monitoring in water, industrial effluent, and wastewater. Equipped with a special alarm function for adjustable high/low pH limits, this device ensures precise results with a 0.01 pH resolution and 2% FS accuracy. Redeem exclusive discounts on purchases and receive full CE-certified reliability. Features include automatic 2/3 point calibration, digital LCD, RS485 MODBUS output, IP65 protection, and robust stainless steel & ABS construction. Installation is quick with included mounting accessories and a 5M cable.

Special Features and Application Excellence

This Online Water Analyzer stands out with special features like high/low pH alarm, 0-14 pH range, and automatic calibration for top-notch reliability. Its robust materials and IP65 protection guarantee durability in demanding environments. Ideal for use in water treatment plants, industrial effluent, and broader wastewater applications, it seamlessly supports continuous, on-site monitoring needs. Its panel or wall mounting options and digital LCD grant elite convenience for operators seeking efficient, real-time water quality analysis.

Flexible Payment Terms and Reliable Supply

We offer competitive payment terms tailored to customer needs for the Online Water Analyzer. With a strong supply ability, we ensure efficient logistics and on-time transportation nationwide. Samples are available on request, allowing you to evaluate this outstanding equipment before making a bulk purchase. Our streamlined order processing, stellar customer support, and expert handling of freight guarantee smooth, worry-free transactions from India's leading manufacturer and supplier.

FAQ's of Online Water Analyzer:

Q: How does the Online Water Analyzer ensure accurate readings?

A: The analyzer uses a glass electrode sensor and supports 2/3 point automatic calibration, offering 0.01 pH resolution and 2% FS accuracy for reliable and precise measurements.

Q: What types of water can this analyzer be used for?

A: It's designed for water, industrial effluent, and wastewater analysis, making it suitable for various industrial and municipal applications where pH monitoring is essential.

Q: What is the typical electrode life and how is it replaced?

A: The electrode typically lasts 12-18 months. Replacement is straightforward with screw terminal connections and threaded process connection, ensuring minimal downtime during maintenance.

Q: Where can the analyzer be installed?

A: With both panel and wall mounting options, the device is adaptable for installation in control rooms, at-line water systems, or directly at processing facilities.

Q: What are the main benefits of the alarm function?

A: The adjustable high/low pH alarm promptly notifies users of out-of-range values, helping to maintain compliance and prevent costly process disruptions.
